- FREQUENCY RANGE : DC~500 MHz
- IMPEDANCE : 50 Ohms
- POWER RANGE : DC~200 Mhz 1KW PEP
300~500 Mhz 500W PEP - ISOLATION : <=50dB
V.S.W.R. : DC~300 MHz <= 1.5
300~500 MHz <= 2.0 - CONNECTORS: SO-239 UHF Coax Type
- DIMENSIONS : 3.7"(W) x 2.1"(H) x 3.3"(D)
- ORIGIN: Taiwan (NOT CHINA)
- Ships quickly and safely from Mississippi.
ONE YEAR WARRANTY
This product is guaranteed by FatCat.Parts against manufacturing defects for one year from the date of purchase.
Here's the easy part: You don't have to have the receipt, or jump through any weird hoops to get it replaced. Just mail it to FatCat.Parts with a note with three pieces of information:
- What happened, and what the defect is
- The username used when it was purchased.
- Your email address
That's it. We'll check it out, and if it's a manufacturing defect, we'll send the replacement (at our expense) to the same address used for the original order. No muss, no fuss, and no hassle. Easy.
